| Model | Working frequency band (GHz) | P-1 (dBm) | Gain (dB) | Noise factor(dB) | Passband fluctuation(±dB) | Standing wave | Bandwidth |
| YJLNAN1G30 | 0.01～1.4 | ≥10 | ≥30 | ≤0.8 | ≤0.5 | 1.3:1 | 20% |
| YJLNAN2G30 | 1.4～2.7 | ≥10 | ≥30 | ≤0.7 | ≤0.5 | 1.3:1 | 20% |
| YJLNAN3G30 | 2.7～3.7 | ≥10 | ≥30 | ≤0.6 | ≤1.0 | 1.3:1 | 30% |
| YJLNAN4G30 | 3.7～4.8 | ≥10 | ≥30 | ≤0.7 | ≤0.5 | 1.3:1 | 20% |
| YJLNAN5G30 | 4.8～5.8 | ≥10 | ≥30 | ≤0.8 | ≤0.5 | 1.3:1 | 20% |
| YJLNAN6G30 | 5.8～7.0 | ≥10 | ≥30 | ≤0.7 | ≤0.5 | 1.3:1 | 30% |
| YJLNAN7G30 | 6.0～8.0 | ≥10 | ≥30 | ≤0.8 | ≤0.5 | 1.3:1 | 30% |
| YJLNAN9G30 | 6.0～12.0 | ≥10 | ≥30 | ≤1.0 | ≤1.0 | 1.3:1 | 25% |
| YJLNAN14G30 | 12.0～16.0 | ≥10 | ≥30 | ≤1.3 | ≤0.5 | 1.3:1 | 25% |
| YJLNAN17G30 | 16.0～18.0 | ≥10 | ≥30 | ≤1.5 | ≤1.0 | 1.3:1 | 25% |
| YJLNAN22G30 | 18.0～26.5 | ≥10 | ≥30 | ≤1.5 | ≤1.0 | 1.3:1 | 25% |
| YJLNAN35G30 | 26.5～44.5 | ≥10 | ≥30 | ≤1.5 | ≤1.0 | 1.3:1 | 25% |
| YJLNAW3G30 | 0.5～3.0 | ≥10 | ≥30 | ≤2.5 | ≤2.0 | 2.0:1 | 100% |
| YJLNAW6AG30 | 1.0～6.0 | ≥10 | ≥30 | ≤2.5 | ≤2.0 | 2.0:1 | 100% |
| YJLNAW6BG30 | 2.0～6.0 | ≥10 | ≥30 | ≤2.5 | ≤2.0 | 2.0:1 | 100% |
| YJLNAW18AG30 | 2.0～18.0 | ≥10 | ≥30 | ≤3.0 | ≤2.5 | 2.0:1 | 100% |
| YJLNAW18BG30 | 6.0～18.0 | ≥10 | ≥30 | ≤2.5 | ≤2.0 | 2.0:1 | 100% |
| YJLNAW26G30 | 18.0～26.5 | ≥10 | ≥30 | ≤2.5 | ≤3.0 | 2.0:1 | 100% |
| YJLNAW44G30 | 26.5～44.5 | ≥10 | ≥30 | ≤2.5 | ≤3.0 | 2.0:1 | 100% |
| |||||||
